IMCR-WW1325
Last updated:
IMCR-WW1325 is a 1325 wood CNC machine for mixed joinery and signs — 1300×2500 table, not a high-volume cabinet nesting cell.
- Working Area
- 1300 × 2500 mm (4×8 ft sheet)
- Spindle Power
- 2.2 kW (3 hp)
- Spindle Speed
- 0 - 24,000 rpm
- Max. Workpiece Height
- 200 mm (7.9 in)
- Spindle Type
- Water-cooled manual tool change
- Tool Capacity
- 0 PC
Woodworking CNC Router IMCR-WW1325 — front view
Comprehensive evaluation aggregated from design engineers, field-service teams, and global user feedback.
- Electrical & Control Professionalism 4.7
Branded controls and electrical components deliver stable, professional-grade operation.
- Mechanical Structural Integrity 4.8
Rigid, well-built structure keeps accuracy stable under continuous production loads.
- Operator Learning Curve 4.6
Straightforward operation and mainstream software compatibility get operators productive quickly.
- Global Component Availability 4.7
Built around mainstream international components that are easy to source worldwide.
- Continuous Production Efficiency 4.7
Designed for low-maintenance, round-the-clock production with minimal downtime.
- Cost-to-Value Proposition 4.8
Export-grade build quality at a competitive price for strong return on investment.
OVERALL PERFORMANCE SCORE 28.3 / 30
IMCR-WW1325 Typical Applications
-
Headboard floral relief Relief carving on furniture
The woodworking 1325 is a 3-axis carving and engraving table: floral headboards, door skins and display parts that a nesting ATC would treat as a different job.
- Industry
- Furniture carving
- Process
- 3D relief / engraving
- Materials
- Solid wood / MDF
-
Door geometric relief Decorative doors and millwork
Geometric door reliefs and custom millwork run on the 1300×2500 table with a manual or water-cooled spindle — not a linear ATC magazine.
- Industry
- Doors / millwork
- Process
- Relief machining
- Materials
- Solid wood
IMCR-WW1325 Core Components & Features
-
Control System
Industrial-grade CNC controller ensures stable, precise operation with intuitive interface and broad CAD/CAM software compatibility.
- Type
- CNC / PLC
- Interface
- Touch screen + USB
- Compatibility
- G-code, mainstream CAD/CAM
-
Drive & Motor System
High-performance servo drive system delivers accurate positioning, fast response and smooth acceleration for consistent machining quality.
- Drive Type
- AC Servo
- Feedback
- Closed-loop encoder
- Overload Capacity
- 300% peak torque
-
Machine Frame & Build
Heavy-duty welded steel structure with stress-relieved base provides vibration dampening and long-term dimensional stability under production loads.
- Material
- Heavy welded steel
- Treatment
- Stress-relieved, precision-machined
- Stability
- Vibration-dampened base
IMCR-WW1325 Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Working Area | 1300 × 2500 mm (4×8 ft sheet) | Bed size for a standard 4×8 ft panel. |
| Max. Workpiece Height | 200 mm (7.9 in) | Maximum workpiece height the gantry can accept. |
| Spindle Type | Water-cooled manual tool change | General-purpose wood spindle. Operator changes tools by hand. |
| Spindle Power | 2.2 kW (3 hp) | Typical 1325 range. Confirm the build on the quote. |
| Spindle Speed | 0 - 24,000 rpm | — |
| Tool Capacity | 0 PC | — |
| Collet Type | ER32 | — |
| Tool Setter | Manual | Operator sets tool length. Typical on a manual-change router. |
| Control System | Syntec / DSP | We match the post-processor to the plant CAM. |
| Drive Motors & Servos | AC servo | Closed-loop servo on the production cell. Brand matched at order. |
| Transmission | X/Y rack and pinion, Z ball screw | — |
| Lubrication System | Automatic | Automatic oiling on this 1325 cell. |
| Positioning Accuracy | ±0.03 mm (±0.001 in) | — |
| Vacuum Zones | Zoned vacuum table | Zoned suction for mixed joinery and sign sheets. Confirm zones on the quote. |
| Dust Collector Power | 5.5 kW (7.4 hp) | — |
| Operating Voltage | 380V / 3 Phase, 50/60Hz (Optional 220V/480V) | Built to the plant supply. |
| Air Pressure Required | 0.6 - 0.8 MPa (87 -116 psi) | — |
Specifications are indicative and vary by configuration. Contact us for the latest data sheet.
The IMCR-WW1325 is the 1325 general-purpose wood CNC in our woodworking CNC router series.
Machine Features
- Heavy welded steel frame for stable high-speed machining
- Vacuum table with zoned suction for nesting
- Compatible with mainstream CAD/CAM software
- Auto lubrication for low maintenance
Packing List
- 1 × Woodworking CNC Router main unit (IMCR-WW1325)
- 1 × control system & operation manual (English)
- 1 × standard tooling & accessory kit
- 1 × set of spare wearing parts
- Export-standard plywood case / film + steel-belt fixing
IMCR-WW1325 Frequently Asked Questions
How much does the Woodworking CNC Router IMCR-WW1325 cost?
Pricing for the Woodworking CNC Router IMCR-WW1325 typically falls in the $12,100 – $20,600 range depending on configuration, tooling and optional accessories. Contact us for a tailored quotation for your production needs.
What is the delivery lead time for the IMCR-WW1325?
Standard configurations usually ship within 15–30 working days after order confirmation. Customised builds may take longer; our sales team will confirm an exact schedule for your order.
Do you provide installation, commissioning and operator training?
Yes. Our engineers provide layout planning, on-site or remote installation, commissioning and operator training, backed by responsive global after-sales support.
What power supply does the IMCR-WW1325 require?
It runs on AC 380V, 3-phase, 50/60Hz and can be customised to match your local mains supply on request.
What warranty and support are included?
The Woodworking CNC Router IMCR-WW1325 comes with a 12-month limited warranty, plus free lifetime technical support for end-users and dealers.
