IMCR-5A1325
Last updated:
IMCR-5A1325 is IndexMACH’s 1325 (1300×2500 mm / 4×8 ft) swing-head 5-axis CNC router for compound curves, moulds and multi-face wood or composite parts in one clamp — also available as 1530 (5×10 ft) / 2030 (~6.5×10 ft) / 2040 (6.5×13 ft) and custom table sizes.
- Working Area
- 1300 × 2500 mm (4×8 ft sheet) Also available: 1530 (1500×3000 mm / 5×10 ft), 2030 (2000×3000 mm / ~6.5×10 ft), 2040 (2000×4000 mm / 6.5×13 ft) and custom table sizes
- Spindle Power
- 9 kW (12.1 hp)
- Spindle Speed
- 0 - 18,000 rpm
- Max. Workpiece Height
- 500 mm (19.7 in)
- Spindle Type
- Air-cooled Automatic Tool Changer Spindle
- Tool Magazine Type
- Linear ATC
IMCR-5A1325 5-axis 1325 CNC router — Main View
Comprehensive evaluation aggregated from design engineers, field-service teams, and global user feedback.
- Electrical & Control Professionalism 4.7
Branded controls and electrical components deliver stable, professional-grade operation.
- Mechanical Structural Integrity 4.8
Rigid, well-built structure keeps accuracy stable under continuous production loads.
- Operator Learning Curve 4.6
Straightforward operation and mainstream software compatibility get operators productive quickly.
- Global Component Availability 4.7
Built around mainstream international components that are easy to source worldwide.
- Continuous Production Efficiency 4.7
Designed for low-maintenance, round-the-clock production with minimal downtime.
- Cost-to-Value Proposition 4.8
Export-grade build quality at a competitive price for strong return on investment.
OVERALL PERFORMANCE SCORE 28.3 / 30
IMCR-5A1325 Typical Applications
-
Chair / seating — curved shell machining
Compound curved furniture surface Seating & curved furniture
Furniture and seating plants pick the IMCR-5A1325 when chair shells, armrests, seat pans and sculpted solid-wood or laminated parts need compound curves finished without flipping the blank onto a second fixture. The swing head tilts on two rotary axes so the tool stays normal to the surface while the linear ATC swaps roughing and finishing bits in one program on the 1300×2500 table. Clamp solid wood, plywood or engineered board on the zoned vacuum bed — or a simple fixture for tall arms — so hold-down stays through undercuts. Stay on this 5-axis CNC router when both rotary axes must move together; angled side faces that need only one swivel stay on the 4-axis CNC router.
- Industry
- Seating / furniture
- Process
- 5-axis contouring & undercuts
- Workpiece
- Chair shells, arms, seat pans
- Materials
- Solid wood / plywood / engineered board
- Table
- 1300×2500 mm (4×8 ft)
- Also available
- 1530 (5×10 ft) / 2030 (~6.5×10 ft) / 2040 (6.5×13 ft) and custom table sizes
- Why 5-axis
- Dual rotary keeps the tool normal on compound curves
-
Car model machining — swing-head close-up Car model / styling mold on the bed
Pattern mold — compound-curve carving Automotive models & pattern moulds
Model shops and pattern makers use the IMCR-5A1325 when a car-body plug, styling clay master or foam pattern needs continuous 3D surfaces and undercuts finished in one clamp. The swing-head spindle tracks compound curves while the ATC swaps roughing and finishing tools so the blank stays on the 1300×2500 bed. Typical blanks are MDF, polyurethane foam and epoxy tooling board; zone the vacuum table or fixture tall plugs so suction does not drop on open faces. This cell is a wood/composite 5-axis CNC router — not a metal gantry mill; heavy steel moulds belong on gantry CNC milling machines.
- Industry
- Automotive / pattern / composites molds
- Process
- 5-axis surface machining & undercuts
- Workpiece
- Car plugs, styling masters, foam patterns
- Materials
- MDF / PU foam / epoxy tooling board
- Table
- 1300×2500 mm (4×8 ft)
- Also available
- 1530 (5×10 ft) / 2030 (~6.5×10 ft) / 2040 (6.5×13 ft) and custom table sizes
- Why 5-axis
- Simultaneous dual rotary for continuous 3D surfaces
-
Marine plug / yacht mold sample
Instrument blank — multi-face contouring
Sculpted millwork / relief sample Marine plugs, instruments & sculpted millwork
Boat yards, instrument makers and premium millwork shops use the IMCR-5A1325 when hull or deck plugs, guitar blanks, relief panels and sculpted architectural parts need multi-face curves finished without a second setup. The swing head reaches faces a flat ATC CNC router cannot see; the linear ATC keeps roughing and finishing in one program on the 1325 table. Typical materials are timber, laminated wood, MDF and light composites. Flat cabinet nests and sign sheets stay on cabinet CNC or ATC 1325 cells — this machine earns its keep on shaped, multi-face work that drives a quote.
- Industry
- Marine / instruments / premium millwork
- Process
- 5-axis multi-face contouring
- Workpiece
- Hull plugs, guitar blanks, relief panels
- Materials
- Timber / laminated wood / MDF / light composites
- Table
- 1300×2500 mm (4×8 ft)
- Also available
- 1530 (5×10 ft) / 2030 (~6.5×10 ft) / 2040 (6.5×13 ft) and custom table sizes
- Why 5-axis
- One clamp for curves and faces a 3-axis nest cannot reach
IMCR-5A1325 Core Components & Features
-
Control System
Syntec industrial CNC keeps 5-axis swing-head programs stable, with a keypad operator panel and post-processors matched to mainstream CAD/CAM.
- Type
- Industrial CNC
- Interface
- Keypad panel + USB
- Compatibility
- G-code, mainstream CAD/CAM
-
Drive & Motor System
Closed-loop AC servos hold position under load so dual-rotary contouring stays smooth through roughing and finishing passes.
- Drive Type
- AC Servo
- Feedback
- Closed-loop encoder
- Overload Capacity
- 300% peak torque
-
Swing-Head ATC Spindle
An air-cooled ATC spindle on the swing head changes ISO30 tools automatically so roughing and finishing stay on the same 5-axis program.
- Power
- 9 kW
- Speed
- 0 - 18,000 rpm
- Tool holder
- ISO30
- Collet
- ER32
- Magazine
- Linear ATC
-
Machine Frame & Build
Heavy-duty welded steel structure with stress-relieved base provides vibration dampening and long-term dimensional stability under production loads.
- Material
- Heavy welded steel
- Treatment
- Stress-relieved, precision-machined
- Stability
- Vibration-dampened base
IMCR-5A1325 Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Working Area | 1300 × 2500 mm (4×8 ft sheet) | This page is the 1325 (1300×2500 mm / 4×8 ft) build. Same architecture also ships as 1530 (1500×3000 mm / 5×10 ft), 2030 (2000×3000 mm / ~6.5×10 ft), 2040 (2000×4000 mm / 6.5×13 ft) and custom table sizes — confirm size on the quote. |
| Max. Workpiece Height | 500 mm (19.7 in) | Standard feed / clearance height 500 mm. Custom heights available to match the job. |
| Spindle Type | Air-cooled Automatic Tool Changer Spindle | Swing-head ATC spindle for 5-axis contouring on wood and composites. |
| Spindle Power | 9 kW (12.1 hp) | Confirm the build on the quote — heavier composites take the upper end. |
| Spindle Speed | 0 - 18,000 rpm | — |
| Tool Magazine Type | Linear ATC | Automatic tool change for multi-tool 5-axis programs. |
| Tool Holder | ISO30 | — |
| Collet Type | ER32 | — |
| Tool Setter | Automatic | Automatic tool-length measurement before the program. |
| Control System | Syntec | Syntec industrial CNC with a keypad operator panel. We match the post-processor to the plant CAM. |
| Drive Motors & Servos | AC servo | Closed-loop servo on the production cell. Brand matched at order. |
| Transmission | X/Y rack and pinion, Z ball screw | — |
| Lubrication System | Automatic | Standard automatic oiling on this ATC cell. |
| Positioning Accuracy | ±0.03 mm (±0.001 in) | — |
| Vacuum Zones | Zoned vacuum table | Hold-down for sheet and fixture work. Confirm zones on the quote. |
| Operating Voltage | 380V / 3 Phase, 50/60Hz (Optional 220V/480V) | Built to the plant supply. |
| Air Pressure Required | 0.6 - 0.8 MPa (87 -116 psi) | — |
| Dust Collector | Not included | Dust extraction is not supplied as standard on this cell. |
Specifications are indicative and vary by configuration. Contact us for the latest data sheet.
The IMCR-5A1325 is IndexMACH’s 1325 (1300×2500 mm / 4×8 ft) 5-axis CNC router — a swing-head CNC router for compound curves, moulds and multi-face wood or composite parts finished in one clamp. The same architecture also ships as 1530 (1500×3000 mm / 5×10 ft), 2030 (2000×3000 mm / ~6.5×10 ft), 2040 (2000×4000 mm / 6.5×13 ft) and custom table sizes when the blank is wider. Furniture seating plants, pattern shops, marine plug makers and instrument builders use the dual rotary axes so the tool stays normal to the surface while the linear ATC swaps roughing and finishing bits without flipping the blank.
Syntec keypad control accepts G-code from mainstream CAD/CAM; we match the post-processor at commissioning. Standard clearance is 500 mm (custom heights available). Dust extraction is not included as standard — plan plant suction or add a collector on the quote. Layout, installation and operator training ship with the machine.
Who buys the IMCR-5A1325?
Seating & furniture — chair shells, arms and sculpted laminated parts that need continuous curves, not just a bevelled edge.
Automotive & pattern moulds — car-body plugs, styling masters and foam patterns in MDF, PU foam or epoxy tooling board.
Marine, instruments & premium millwork — hull/deck plugs, guitar blanks, relief panels and sculpted architectural parts.
Is the IMCR-5A1325 right for this shop?
Yes if daily parts need both rotary axes moving together — compound surfaces, undercuts and several faces in one setup — and the blank fits a 1325 table or fixture.
No if almost every job is flat sheet nesting (buy ATC or cabinet CNC), or only one swivel is enough for side faces (buy the IMCR-4A1325). Heavy metal moulds belong on gantry CNC milling machines.
Machine Features
- Swing-head dual rotary for one-clamp compound curves and undercuts
- 1325 (1300×2500 mm / 4×8 ft) vacuum table on this page — also 1530 (5×10 ft) / 2030 (~6.5×10 ft) / 2040 (6.5×13 ft) and custom table sizes
- Air-cooled 9 kW ATC spindle, 0–18,000 rpm, ISO30 / ER32
- Linear ATC magazine for multi-tool 5-axis programs
- Syntec industrial CNC with keypad operator panel
- 500 mm standard clearance; custom heights available
- Closed-loop AC servos; automatic lubrication
- Dust collector not included — plant extraction or quote option
Packing List
- 1 × 5-Axis CNC Router main unit (IMCR-5A1325)
- 1 × control system & operation manual (English)
- 1 × standard tooling & accessory kit
- 1 × set of spare wearing parts
- Export-standard plywood case / film + steel-belt fixing
Next step
Send part photos or STEP files, materials, target cycle time, plant voltage (220/380 V, phase, Hz) and whether you already run 5-axis CAM. We map that to spindle, clearance height and post-processor — then return a firm quote. Request a quote, or browse the 5-axis CNC router series and other CNC routers.
IMCR-5A1325 Frequently Asked Questions
How much does the 5-Axis CNC Router IMCR-5A1325 cost?
Pricing for the IMCR-5A1325 typically falls in the $23,000 – $65,000 range depending on spindle, magazine, control, clearance height and options. Ask for a quote with part photos, materials and plant voltage.
What jobs is the IMCR-5A1325 built for?
Compound curves and multi-face wood or composite parts that need both rotary axes moving together — chair shells, automotive and marine plugs, instrument blanks and sculpted millwork. This page is the 1325 (1300×2500 mm / 4×8 ft) build; 1530 (1500×3000 mm / 5×10 ft), 2030 (2000×3000 mm / ~6.5×10 ft), 2040 (2000×4000 mm / 6.5×13 ft) and custom table sizes share the same architecture. Flat sheet nests belong on ATC or cabinet CNC; single-swivel side faces stay on 4-axis CNC routers.
What table sizes are available besides this 1325?
This page is the fixed 1325 (1300×2500 mm / 4×8 ft) SKU. The same 5-axis CNC router architecture also ships as 1530 (1500×3000 mm / 5×10 ft), 2030 (2000×3000 mm / ~6.5×10 ft), 2040 (2000×4000 mm / 6.5×13 ft) and custom table sizes — send sheet or blank size with the quote request.
When should I choose 5-axis over 4-axis?
Choose this 5-axis CNC router when the tool must approach from arbitrary angles and both rotary axes move in the same program. If only one swivel (A-axis) is enough for bevels and side faces, the IMCR-4A1325 is usually the right buy.
Is a dust collector included with the IMCR-5A1325?
No. Dust extraction is not supplied as standard — use the plant system or add a collector on the quote. Confirm hose size and power with sales before shipment.
What control and CAM setup does the IMCR-5A1325 use?
Syntec industrial CNC with a keypad operator panel. We match the post-processor to the plant CAD/CAM at commissioning. Send sample toolpaths with the enquiry so rotary limits and the post are checked before the first production job.
What workpiece height and materials does the IMCR-5A1325 handle?
Standard clearance is 500 mm; custom heights are available. Typical materials are solid wood, plywood, MDF, PU foam, epoxy tooling board and light composites. It is not a metal gantry mill — steel moulds need gantry CNC milling.
What is the delivery lead time for the IMCR-5A1325?
Standard configurations usually ship within 15–30 working days after order confirmation. Custom clearance, voltage or magazine builds may take longer; sales confirms the date on the order. Layout, commissioning and operator training are included.
What power supply does the IMCR-5A1325 require?
Standard is AC 380V, 3-phase, 50/60 Hz. 220V and 480V builds are available to match the plant supply.
What warranty and support are included?
The IMCR-5A1325 ships with a 12-month limited warranty, plus free lifetime technical support for end-users and dealers.
